RJ/ TRANSFORMER SOCKET RJ/ Transformer 插座

RJ45 network interface series

RJ45-8305 SATA+USB2.0

RJ45網(wǎng)絡(luò)接口 FEATURE ?17.30mm*20.10mm ?SATA+USB2.0 APPLICATIONS ? LCD TV, router, switch, tablet PC, projector

檔案下載產(chǎn)品詢價

Characteristics	Specification
額定電壓/Rated voltage	125VAC RMS
電流/Current	1.5AMP
接觸電阻/Contact resistance	35MILLIOHMS MAX
絕緣電阻/Insulation resistance	USB:1000M ohm MIN SATA:100M ohm MIN
介電強度/Dielectric strength	USB:750VAC RMS 50HZ 1MIN SATA:500VAC RMS 50HZ 1MIN

Unit:mm

Model	Dimensions
RJ45-8305 SATA+USB2.0
