Waterproof panel mounting solder cup type DB15 male connector
D-SUB-15PA-1
防水焊杯式DB15母座
FEATURE
? 47.80mm*21.10mm
? Mounted on any panel or enclosure 0.078 inches (1.98mm) thick or less
? Available in DB9, DB25 and HD15 sizes
APPLICATIONS
Computers, industrial control equipment, image workstations, microwave TX/RX, base stations, electronic medical equipment
